Air Conditioning Systems
MSY-JX
Features
Anti-Mold Filter
Dual-Barrier-Coating
Electrostatic Anti-allergy Enzyme Filter
Error Code display on Remote Controller
Fast Cooling Mode
Grooved Piping
Heat Caulking Fixing Method
High Density Filter
Horizontal vane swing
Joint Lap DC Motor
Long Airflow
Luminous Button
Vector Wave Eco Inverter
Technical Specifications
| Type (Cooling) |
|---|
| Indoor Unit |
| MSY-JX18VF |
| Outdoor Unit |
| MUY-JX18VF |
| Performance Parameters | |
|---|---|
| Capacity (Tr) | 1.5 Tr |
| Star Rating - As Per BEE | 3 Star  |
| Power Supply | 230 V / 50 Hz / Single Phase |
| Rated Capacity | 5200 W |
| Rated Power Input | 1900 W |
| ISEER | 3.95 |
| Rated Current (Amps) | 8.4 |
| Indoor Air Flow (CMH) (Turbo/Hi/Mi/Lo) | 966/845/666/504/390 |
| Indoor Noise(Low/Mid/Hi/Turbo Speed) | 49/44/40/33/26 |
| Refrigerant | R32  |
| Dimensions & Weight | |||
|---|---|---|---|
| Indoor unit | Dimensions (Wx D x H) | mm | 923 x 262 x 305 |
| Net Weight | kg | 11 | |
| Outdoor unit | Dimensions (H x W x D) | mm | 780 x 294 x 545 |
| Net Weight | kg | 27 | |
| Connecting Pipe |
Liquid and Gas Side Dia | mm | 6.35/12.7 |
| Maximum Length | mm | 20 | |
| Maximum Elevation | m | 10 | |
| Ambient Operating Range | °C | 52 | |
