Air Conditioning Systems
RAY-Series
Total Capacity / Model Name
Ray-Se22Vg | 1.8 Tr
Capacity
1.8 Tr
Rating
Refrigerant
MRP₹ 55000
Catalogue
Add to Cart
Features
DC Inverter
DC fan motor
Auto Restart
Fast Cool
Technical Specifications
| Type (Cooling) |
|---|
| Indoor Unit |
| RAY-SE22VG |
| Outdoor Unit |
| RBY-SE22VG |
| Performance Parameters | |
|---|---|
| Capacity (Tr) | 1.8 Tr |
| Star Rating - As Per BEE | 3 Star |
| Power Supply | 230 V / 50 Hz / Single Phase |
| Rated Capacity | 6250 W |
| Rated Power Input | 1970 W |
| ISEER | 4.00 |
| Rated Current (Amps) | 8.9 |
| Indoor Air Flow (CMH) (Turbo/Hi/Mi/Lo) | 1050/920/830/790 |
| Indoor Noise(Low/Mid/Hi/Turbo Speed) | 46/47/49/51 |
| Refrigerant | R32 |
| Dimensions & Weight | |||
|---|---|---|---|
| Indoor unit | Net Dimensions (W x D x H) | mm | 1000 x 230 x 295 |
| Net Weight | kg | 11.0 | |
| ODU Dimension | Net Dimensions (W x D x H) | mm | 781 x 281 x 555 |
| Net Weight | kg | 30 | |
| Connecting Pipe | Liquid and Gas Side | mm | 12.7/6.3 |
| Maximum Length | m | 20 | |
| Maximum Elevation | m | 10 | |
| Ambient Operating Range | °C | 48° | |
