Air Conditioning Systems
RAZ-SE
Features
Anti-Mold Filter
Econo Cool
Hot and Cold
Self-diagnostic
Technical Specifications
| Type (Cooling) |
|---|
| Indoor Unit |
| RAZ-SE18VG |
| Outdoor Unit |
| RBZ-SE18VG |
| Performance Parameters | |
|---|---|
| Capacity (Tr) | 1.5 Tr |
| Star Rating - As Per BEE | 3 Star  |
| Power Supply | 230 V / 50 Hz / Single Phase |
| Capacity (Rated Min-Max) | 5200 W |
| Total Input (Rated Min-Max) | 1590 W |
| ISEER | 4.2 |
| Rated Current (Amps) | 7.26 |
| Indoor Air Flow (CMH) (Turbo/Hi/Mi/Lo) | 1050 / 920 / 830 / 790 |
| Indoor Noise(Low/Mid/Hi/Turbo Speed) | 44/45/48/51 |
| Compressor, Refrigerant & Ambient Operations | |
|---|---|
| Refrigerant | R32  |
| Dimensions & Weight | |||
|---|---|---|---|
| Indoor unit | Net Dimensions (W x D x H) | mm | 1000x230x295 |
| Weight | kg | 11.5 | |
| Outdoor unit | Net Dimensions (W x D x H) | mm | 810x301x594 |
| Weight | kg | 31.3 | |
| Connecting Pipe |
Liquid and Gas Side Dia | mm (inches) | 12.7 / 6.35 |
| Maximum Length | m | 15 | |
| Maximum Elevation | m | 10 | |
| Ambient Operating Range | °C | -7° to 48° | |
