Air Conditioning Systems
MS-AJZ
Features
4 Way Swing
DC Fan Motor
Eco Cool
Grooved Piping
LCD Remote Control
Wide & Long Airflow
Technical Specifications
| Type (Cooling) |
|---|
| Indoor Unit |
| MS-AJZ22VF |
| Outdoor Unit |
| MU-AJZ22VF |
| Performance Parameters | |
|---|---|
| Capacity (Tr) | 1.8 Tr |
| Star Rating - As Per BEE | 2 Star  |
| Power Supply | 230 V / 50 Hz / Single Phase |
| Rated Capacity | 6200 W |
| Rated Power Input | 1758 W |
| ISEER | 3.53 |
| Rated Current (Amps) | 8.02 |
| Indoor Air Flow (m3/h) (Turbo/Hi/Mi/Lo) | 1050 |
| Indoor Noise(Low/Mid/Hi/Turbo Speed) | 40/42/44/50 |
| Refrigerant | R32 |
| Dimensions & Weight | |||
|---|---|---|---|
| IDU Dimension | Net Dimensions (W x D x H) | mm | 1000 x 230 x 295 |
| Net Weight | kg | 11 | |
| Outdoor unit | Net Dim (W * D * H) | mm | 852 x 310 x 692 |
| Net Weight | kg | 46 | |
| Connecting Pipe | Liquid and Gas Side Dia | mm | 15.88 / 6.35 |
| Maximum Length | m | 20 | |
| Maximum Elevation | m | 10 | |
| Ambient Operating Range | °C | 48° | |
| Installation Kit | (Includes Copper Kit/Insulation/Wire) | Included | |
