Air Conditioning Systems
RAM-Series
Total Capacity / Model Name
Ram-Ae18Vg | 1.5 Tr
Capacity
1.5 Tr
Rating
Refrigerant
MRP₹ 50600
Catalogue
Add to Cart
Features
DC fan motor
Auto Restart
Blue Fin
Fast Cool
Technical Specifications
| Type (Cooling) |
|---|
| Indoor Unit |
| RAM-AE18VG |
| Outdoor Unit |
| RBM-AE18VG |
| Performance Parameters | |
|---|---|
| Capacity (Tr) | 1. 5 Tr |
| Star Rating - As Per BEE | 2 Star |
| Power Supply | 230 V / 50 Hz / Single Phase |
| Rated Capacity | 5100 W |
| Rated Power Input | 1450 W |
| ISEER | 3.52 |
| Rated Current (Amps) | 6.5 |
| Indoor Air Flow (CMH) (Turbo/Hi/Mi/Lo) | 1080/950/840/790 |
| Indoor Noise(Low/Mid/Hi/Turbo Speed) | 43/45/47/49 |
| Refrigerant | R32 |
| Dimensions & Weight | |||
|---|---|---|---|
| Indoor unit | Net Dimensions (W x D x H) | mm | 1000 x 230 x 295 |
| Net Weight | kg | 11.0 | |
| Outdoor unit | Net Dimensions (W x D x H) | mm | 781 x 241 x 557 |
| Net Weight | kg | 35 | |
| Connecting Pipe | Liquid and Gas Side Dia | mm | 12.7/6.35 |
| Maximum Length | m | 15 | |
| Maximum Elevation | m | 10 | |
| Ambient Operating Range | °C | 48° | |
